GENERATOR
24 Bit sigma-delta D/A Converter
Frequency range: 1Hz-45kHz
Frequency accuracy: better than 0.01%
Frequency resolution: 0.01Hz
Output impedance: 150Ohm
Max output level (Sine): 13dBu (3.46Vrms)
Attenuation: 0.1 dB steps to full mute
THD+Noise(Sine): 0,008%

AC ANALYZER
24 bit sigma-delta A/D Converter
Input range: +40 ÷ -40dBV
Max input acceptance: +40dBV (283Vpp)
Input impedance: 64kOhm (5.6kOhm mic)
Phantom power supply: 8.2V

DC ANALYZER
12 bit A/D Converter
Input range: ± 6.5V

MISCELLANEOUS
Sampling frequencies: 96kHz and 48kHz
Connections: analog RCA in and out
Digital connection: USB 2.0 port
Power supply: USB powered (480 mA)
Dimensions (cm): 9(w)x12(d)x2.5(h)
Weight: 0.3 kg

MIC-02 MICROPHONE
TYPE: Condenser Electret
Accuracy (direct field): ±1 dB 20Hz÷10KHz, ±2 dB 10÷20KHz
Maximum level: 130 dB SPL
Sensitivity (average): 13mV/Pa
Dimensions: 8mm diameter, 12 cm long
